45° Short Radius Elbow

Neminox Steel & Engineering Co. are Manufacturer, Exporter and Supplier of Butt weld 45 degree Short Radius Elbow. Butt weld 45 degree Short Radius Elbow manufactured using superior grade raw materials. Butt weld 45 degree Short Radius Elbow are used for connecting pipes of different diameters and find wide applications in various chemicals, construction industries, paper, cement & ship builders.



Type : Butt weld (BW)
Standards : ASME / ANSI - B 16.9
ASTM A403 - ASME SA403 - 'Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings'
API 590-605
ASME B16.9 - 'Factory-Made Wrought Buttwelding Fittings'
ASME B16.25 - 'Buttwelding Ends'
ASME B16.28 - 'Wrought Steel Buttwelding Short Radius Elbows and   Returns'
MSS SP-43 - 'Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications'
Dimension : ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness : Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule : Sch 5 TO Sch XXS.
Size : 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)



Materials and Grade:

Stainless Steel 45 degree Short Radius Elbow:

ASTM A403 WP316/316L
ASTM A403 WP304/304L
ASTM A182 F316L, 304L
DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel 45 degree Short Radius Elbow:

ASTM A234 Gr. WPB
ASTM A420 Gr. WPL6
ASTM A105
ASTM A350 Gr. LF2

Nickel Alloy 45 degree Short Radius Elbow:

Monel 400 & 500,
Inconel 600 & 625,
Incolloy 800, 825,
Hastelloy C22, C276,
Hastelloy,
Nickel,
Monel,
Inconel,
Alloy20,
Copper Nickel
Cupro-Nickel 90/10
Cupro-Nickel 70/30

Alloy steel 45 degree Short Radius Elbow:

ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91



ASME B16.9 Butt weld 45 degree Short Radius Elbow Dimensions



Nom.
Pipe
Size
Pipe
Sched.
or No.
Center-
to-end
Dimen.
Outside
Dia.
Inside
Dia.
Wall
Thick.
Approx.
Weight
(lb.)
F OD ID T
     STANDARD WEIGHT
1/2 40 5/8 0.840 0.622 0.109 0.1
3/4 40 7/16 1.050 0.824 0.113 0.1
1 40 7/8 1.315 1.049 0.133 0.2
1 1/4 40 1 1.660 1.380 0.140 0.4
1 1/2 40 1 1/8 1.900 1.610 0.145 0.5
2 40 1 3/8 2.375 2.067 0.154 0.9
2 1/2 40 1 3/4 2.875 2.469 0.203 1.5
3 40 2 3.500 3.068 0.216 2.5
3 1/2 40 2 1/4 4.000 3.548 0.226 3.5
4 40 2 1/2 4.500 4.026 0.237 4.8
5 40 3 1/8 5.563 5.047 0.258 7.8
6 40 3 3/4 6.625 6.065 0.280 12
8 40 5 8.625 7.981 0.322 23
10 40 6 1/4 10.750 10.020 0.365 42
12 - 7 1/2 12.750 12.000 0.375 61
14 30 8 3/4 14.000 13.250 0.375 79
16 30 10 16.000 15.250 0.375 103
18 - 11 1/4 18.000 17.250 0.375 132
20 20 12 1/2 20.000 19.250 0.375 160
22 20 13 1/2 22.000 21.250 0.375 195
24 20 15 24.000 23.250 0.375 238
     EXTRA STRONG
Nom.
Pipe
Size
Pipe
Sched.
or No.
Center-
to-end
Dimen.
Outside
Dia.
Inside
Dia.
Wall
Thick.
Approx.
Weight
(lb.)
F OD ID T
1/2 80 5/8 0.840 0.546 0.147 0.2
3/4 80 7/16 1.050 0.742 0.154 0.3
1 80 7/8 1.315 0.957 0.179 0.4
1 1/4 80 1 1.660 1.278 0.191 0.5
1 1/2 80 1 1/8 1.900 1.500 0.200 0.6
2 80 1 3/8 2.375 1.939 0.218 1.1
2 1/2 80 1 3/4 2.875 2.323 0.276 2.1
3 80 2 3.500 2.900 0.300 3.5
3 1/2 80 2 1/4 4.000 3.364 0.318 4.8
4 80 2 1/2 4.500 3.826 0.337 6.5
5 80 3 1/8 5.563 4.813 0.375 11
6 80 3 3/4 6.625 5.761 0.432 18
8 80 5 8.625 7.625 0.500 35
10 60 6 1/4 10.750 9.750 0.500 56
12 - 7 1/2 12.750 11.750 0.500 80
14 - 8 3/4 14.000 13.000 0.500 100
16 40 10 16.000 15.000 0.500 131
18 - 11 1/4 18.000 17.000 0.500 172
20 30 12 1/2 20.000 19.000 0.500 210
22 30 13 1/2 22.000 21.000 0.500 259
24 - 15 24.000 23.000 0.500 302



Ansi 16.9 tolerances – 45 Degree short radius elbow

DIMENSIONAL TOLERANCES - ELBOWS
For all fittings Elbows 90/45 deg 180° Returns
Nominal Pipe Size (NPS) Outside Ø
at Bevel
Inside Ø
at End
Wall Thickness
t / t1
Center to End Dim. A-B-C-M Center to Center Dim.
O
Back to Face Dim.
K
Align- ment of Ends
U
1/2 a 2 1/2 1 0,8 Not 2 7 7 1
3 a 3 1/2 1 1,6 less 2 7 7 1
4 +2 -1 1,6 than 2 7 7 1
5 a 6 +3 -1 1,6 87,50% 2 7 7 1
8 2 1,6 of nominal 2 7 7 1
10 +4 -3 3,2 tickness 2 7 7 2
12 a 18 +4 -3 3,2   3 10 7 2
20 a 24 +6 -5 4,8 3 10 7 2
26 a 30 +7 -5 4,8 3 ..... ..... .....
32 a 48 +7 -5 4,8   5 ..... ..... .....



Angularity Tolerances
ND Max off angle Max off plane
Q P
1/2 a 4 1 2
5 a 8 2 4
10 a 12 3 5
14 a 16 3 7
18 a 24 4 10
26 a 30 5 10
32 a 42 5 13
44 a 48 5 20
